ROCKFORD FOSGATE, PRIME 10″ R2 4-OHM DVC SUBWOOFER

Specifications:

• Magnet Weight (oz)
  • 43 oz. (1.22 kg)
• Size
  • 10″
• Xmax (mm)
  • 6.5
• Shipping Weight
  • 8.8 Lbs. (3.99 kg)
• SPL (dB @ 1w/1m)
  • 86.6
• Woofer Displacement
  • 0.039 cu. ft. (1.1 Liters)
• Le (mH)
  • 3.9
• Cutout Diameter
  • 9.125 in. (232 mm)
• Voice Coil Diameter
  • 2″ (51 mm)
• Nominal Impedance
  • Dual 4-Ohm
• Speaker Connector
  • Dual 12 AWG compression
• Fs (Hz)
  • 34.9
• Mounting Depth
  • 4.319 in. (109 mm)
• Qts
  • 0.53
• Qes
  • 0.58
• Qms
  • 6.44
• Vas (Liters)
  • 38.4
• Power Handling (Watts RMS)
  • 250 Watts RMS
  • 500 Watts Max
• CEA-2031 Compliant
• Re (Ohms)
  • 7.83
• Sd (cm²)
  • 339.8
• Subwoofer Type
  • Standard
• Voice Coil Type
  • Dual Voice Coil
• Sealed Box Volume (Vb)
  • 0.59 cu. ft. (16.7 Liters)
• Vented Box Volume (Vb)
  • 1.4 cu. ft. (39.6 Liters)
