Specifications:
- Powerful mono performance. Delivers up to 1525 watts of maximum dynamic power in a dedicated single-channel configuration.
- Efficient Class D design. High-efficiency MOSFET circuitry provides heavy-hitting bass while generating less heat.
- Precision bass management. Includes a selectable low-pass crossover and a wired remote for easy bass adjustments from the driver’s seat.
- Ultra-compact footprint. Measuring just 1.99” x 6.53” x 9.92”, this amplifier fits easily into tight spaces without sacrificing output.
- Certified power ratings. CTA-2006-D certification ensures the power ratings are accurate and independently verified for reliable performance.
- Variable gain: 200 mV – 6 V
- Bass boost: Variable at 45 Hz (0–6 dB)
- Speaker impedance: 1, 2, or 4 ohm stable
Continuous Power Output (1% THD+N):
- 500 watts RMS @ 4 ohms
- 870 watts RMS @ 2 ohms
- 1310 watts RMS @ 1 ohm
Maximum Dynamic Power (10% THD+N):
- 1525 watts peak power
- Frequency response: 20 Hz – 250 Hz
- Signal-to-noise ratio: 89 dBA (reference: 1 watt RMS)
- Total harmonic distortion (THD+N): <0.04% at 1 watt RMS
