JENSEN, JAONE 1525W 1-CHANNEL CLASS D MOSFET AMPLIFIER – CTA-2006-D CERTIFIED

Specifications:

• Powerful mono performance. Delivers up to 1525 watts of maximum dynamic power in a dedicated single-channel configuration.

• Efficient Class D design. High-efficiency MOSFET circuitry provides heavy-hitting bass while generating less heat.

• Precision bass management. Includes a selectable low-pass crossover and a wired remote for easy bass adjustments from the driver’s seat.

• Ultra-compact footprint. Measuring just 1.99” x 6.53” x 9.92”, this amplifier fits easily into tight spaces without sacrificing output.

• Certified power ratings. CTA-2006-D certification ensures the power ratings are accurate and independently verified for reliable performance.
• Variable gain: 200 mV – 6 V

• Bass boost: Variable at 45 Hz (0–6 dB)

• Speaker impedance: 1, 2, or 4 ohm stable


Continuous Power Output (1% THD+N):

• 500 watts RMS @ 4 ohms

• 870 watts RMS @ 2 ohms

• 1310 watts RMS @ 1 ohm


 Maximum Dynamic Power (10% THD+N):

• 1525 watts peak power

• Frequency response: 20 Hz – 250 Hz

• Signal-to-noise ratio: 89 dBA (reference: 1 watt RMS)

• Total harmonic distortion (THD+N): <0.04% at 1 watt RMS
