Specifications:
Radio
- High-End CODEM IV High-End World-Tuner
- FM (RDS), AM Tuner
- DAB+ Tuner built-in
Data Carrier
- USB, SD, SDHC (up to 32 GB)
Media player
- Audio from USB/SDHC
- Audio formats MP3, WMA
Bluetooth
- Bluetooth module built-in (HFP, PBAP, A2DP, SPP, AVRCP)
- Twin-Connect
- Phone book access
- Built-in + external microphone
- Navigation audio mix
Input / Output
- 1x front USB
- 1x rear USB
- 1x front Aux-In
- 1x front SDHC slot
- Steering wheel control input (programmable)
Equalizer / Amplfier
- 3-band, semi-parametric equalizer
- Sound presets (Rock, Pop, Classic)
- X-Bass
- 4-channel preamp-out (4V)
- Separate Sub-Out
- 4 x 50-Watt max. power
General
- Vario Colour (RGB for display & button illumination)
- Fix front panel
- Permanent memory
- Short mounting depth
- IR remote control included in delivery
- DAB+ onglas antenna included in delivery
- External BT- mircophone included in delivery
Tech Specs
DAB FEATURES
- DAB / DAB+ : yes/yes
- Band III / L-Band: yes / no
- Service Scan: yes
- Preset Stations: 15 (DAB 1,2,3)
- Ensemble / Programme: yes
- Comfort browsing: yes
- Programme scan: yes
- Service-link DAB-DAB: yes
- Service-link DAB-FM: yes
- Service-link DAB-DAB-FM: yes
- Traffic announcement: yes (via FM RDS TA)
- DLS: YES
- PTY Programme: yes
- Frequency response (Hz) +/- 3 dB: 20-20.000
Analog Radio
- Type of tuner: High-End Automotive Tuner Blaupunkt CODEM
- World tuner (switchable): Eu, Americas, Thailand
- Wave bands: FM 1,2, MW
- Radio Data System (RDS): Alternative Frequency (AF), Radiotext (RT), Clock Time (CT), Enhance Other Networks (EON), Programme Service Name (PS), Programme Types (PTY), Regional Programme (REG), Traffic Announcement (TA), Traffic Program (TP)
- Travelstore: yes (FMT)
- Band Scan / Preset Scan: yes / yes
- Station memory: 25
- Sensitivity: lo / dx
- Interference suppression: yes
- Hi-Cut: yes
- Frequency response (Hz) -3 Db: 30 – 15.000
Bluetooth
- Supported version: Bluetooth 2.1 mit EDR
- Supported profiles: HFP, PBAP, A2DP, AVRCP, SPP
- Pairing (Number of devices): 5
- Pairing Code: 1234
- Hands-free calling: via micro + radio speaker
- Hands-free calling: via microphone + radio speaker
- Hands-free volume: variable
- Microphone: built-in + external microphone
- Key functions: accept / hang-up / reject call / redail
- Phone book access: yes (up to 1.000 entries by phone)
- Twin Connect: yes (2 simultaneously connected phones for telephony)
- Navigation Audio Mix: yes (Navigation commands via A2DP)
- Auto Wake-Up: yes (radio switched off / ignition on)
Media Player
- Playback format: MP3 WMA
- Title display : ID3-tag (version 2), file, folder
- Folder- & file browsing: yes (w/o track interruption)
- Multiple folder level from MSD: yes
- iPod, iPhone control: yes (w/o track interruption)
- Fast list browsing: yes (via second encoder)
- Display modes: yes (file, folder, song, artist, album, clock, elapsed time, total time, all mode)
- Display of characters: File name up to 50, tags up to 30
- Variable display scrolling: yes
- Mix / Repeat / Scan: yes / yes / yes
- Fast media reading: yes (from USB, SDHC, SD)
- Number of supported files: > 30.000 from MSD
- Bitrate (kBit/s): 32-320
- Vibrable bitrate: yes
Equalizer
- Number of bands / model: 3 / parametric
- Bass / Treble: yes / yes ( +/- 7 steps)
- Balance / Fader : yes / yes (+/- 9 steps)
- x-bass: yes
- Sound presets: Rock, Pop, Klassik
Amplifier
- Number of Channels: 4
- Max. Power: 4 x 50 Watt
- Sinus power at 14.4 V: 4 X 24Watt (DIN 45324)
Display
- Type / digits: 1-line / 9
- Angle: Wide-view
- Color: Variocolor ( RGB )
- Brightness: adjustable
- Clock display: 24 / 12 hrs
Data Carrier
- USB: 2 x USB 2.0
- Memory cards: SDHC (up to 32 GB), SD, MMC, Formatting USB / SD: FAT 32 FAT 16
INPUTS
- Antenna (number of): 2 (FM ISO + DAB SMB)
- USB (number of / type): 2 (front + rear / standard A-type)
- iPod/iPhone: yes (via front + rear USB)
- Memory cards: yes
- Aux-In (number of , type): 1 front (3,5 mm jack)
- Telephone-mute : yes
- Steering wheel control: yes (analogue programmable)
Output
- Loudspeaker (number of): 4
- Pre-amplifier (channel): 4 (Cinch)
- Pre-amplifier (voltage): 4 Volt
- Variable amplifier delay time: yes
- Sub-Out: yes (Cinch, var. gain/frequency)
General
- Software Update: yes, via USB
- Variable scan-time: yes
- Confirmation-beep: yes (on/off)
- Front panel: Fix-Panel
- Panel / décor-ring color: black/black
- Key illumination: Vario color (RGB)
- Permanent preset storage: yes (settings & presets)
- Demo mode: yes
- Weight (kg): ca. 0,85
- Dimension (mm): 58 x 178 x 110 (H x W X D)
- Voltage supply: 10.5 – 14.4V
- Current consumption: In operation: < 10A
- 10 sec. after switch off: < 3.5 mA
- DAB-onglas antenna: yes (included in delivery)
- IR remote control: yes (included in delivery)
- External BT microphone: yes (included in delivery)
Brand
Blaupunkt
