AUDIOPIPE, 800 WATTS FULL RANGE CLASS D COMPACT AMPLIFIER

Specifications:

• FULL RANGE CLASS D AMPLIFIER: The APMOX-800.1 utilizes advanced pulse-width modulation (PWM) techniques to efficiently deliver power to your speakers, resulting in clearer, louder sound.

• IDEAL COMPACT DESIGN: The sleek and compact design of the APMOX-800.1 makes it easy to integrate into various car, motorcycle, golf cart, and off-road vehicle interiors with limited space, providing flexibility and convenient installation with superior performance.

• DESIGNED WITH ADVANCED MOSFET CIRCUITRY: The APMOX-800.1 utilizes advanced MOSFET circuitry for maximum performance with minimal distortion, making it an ideal choice for your audio system.

• CONTINUOUS POWER OUTPUT (R.M.S.) @ 1%:
  – Mono @ 4 Ohms: 1 x 560W
  – Mono @ 2 Ohms: 1 x 800W

• FREQUENCY RESPONSE (-3dB): 10Hz-500KHz

• CROSSOVER RANGE HIGH AND LOW: 50Hz-500Hz

• THD: 0.08%

• PASS: S/N Rated (A WTG): 87dB

• VARIABLE SUBSONIC FILTER: The APMOX-800.1 owns a built-in subsonic filter which effectively eliminates sound frequency under 50Hz, ensuring high-quality audio output.

• VARIABLE BASS BOOST: With the added benefit of a bass boost control, you can customize your bass levels from 0dB to 12dB, taking your audio to a whole new level.

• VARIABLE HIGH-PASS AND LOW-PASS FILTER: The APMOX-800.1 features a high-pass and low-pass filter switch which allows you to precisely control the frequencies. Plus, with its added X-over control, you can easily control your preference on the crossover for the best audio performance.

• OVERLOAD PROTECTION: The APMOX-800.1 is equipped with overload protection, ensuring a safe and reliable audio experience.

• OVERHEAT PROTECTION: The APMOX-800.1 features an advanced heatsink, designed to provide superior overheat protection.

• REMOTE SUBWOOFER VOLUME CONTROL: The APMOX-800.1 comes equipped with a remote bass control knob, clip LED, and power on/off LED indicator. Easily control your audio sound level and monitor your amplifier’s performance.

• WORKING VOLTAGE: 9-16V

• DIMENSIONS: 4.6” x 5.7” x 2.5”  (L x W x H)  117 x 144 x 64 mm
