- Number of Channels: 1
RMS Power at 1 Ohm 12.6V: 8000W RMS
RMS Power at 2 Ohm 12.6V: 5100W RMS
RMS Power at 4 Ohm 12.6V: 3030W RMS
RMS Power at 1 Ohm 14.4V: 8900W RMS
RMS Power at 2 Ohm 14.4V: 6000W RMS
RMS Power at 4 Ohm 14.4V: 4000W RMS
Supply Voltage: 9.5 ~ 15V
Frequency Response: 10Hz ~ 15KHz
Crossover Low Pass: 50Hz ~ 15KHz
Crossover High Pass: 10Hz ~ 700Hz
Signal to Noise: > 90 dB
Harmonic Distortion: < 0.9 % THD
Input Sensitivity: 0.2V
Input Impedance: 25K OHMS
Impedance Output: 1 OHM
Consumption with Signal Musical: 5.2A ~ 396A
Consumption with Signal Bass: 5.2A ~ 790A
Dimensions (L x W x H): 11.57” x 17.51” x 3”
Weight: 13.9 Lbs - manufacturer warranty only
- click here for warranty
