AUG 10, 2015
Prestige & Pursuit “E” Series Remote Start
Information Update
Ignition & Accessory Relay Selection Bank 3 Feature 23
APS997E, APS787E, APS687E, APS687TWE, APS57E, PRO9776E,
PRO9276E, PRO9556E, AS9234E
Many late model Ford vehicles require the ignition and accessory to turn on to disarm the factory
alarm. The remote start models listed above are selectable to accommodate these vehicles as described
below.
Bank 3 Feature 23 allows the following selections:
Selection 1: No Pulse to Ignition or Accessory upon unlocking of the vehicle.
Selection 2: Pulse Ignition and Accessory with unlocking of the vehicle doors to disarm factory alarm.
Selection 3: Pulse Igntion and Accessory with unlocking of the vehicle doors to disarm the factory
alarm, followed by Pulse After Shut Down which can be used turn off the R.A.P. system where applicable.
Note: When set for Selection 2 or 3 the Ground While Running, (Light Blue ignition 3), is also activated
with unlock to insure your data module, or your UTI (key in a box) functions
____________________________________________________________
AUG 10, 2015
Prestige & Pursuit “E” Series Information Update
Shock Sensor Selection Settings Bank 3 Feature 15
The installation guides have been updated to revision “a” to explain these settings so the installer
can best select the proper setting for their customer’s application.
When using the APS997E, APS787E, PRO9776E & AS9234E, we have found in some applications
they will false trigger upon remote start. We can attributed this to the proper shock sensor setting of
Bank 3 Feature 15.
These false triggers are remedied by properly setting the system up for the vehicle the Remote Start
is installed in. The selections are as follows:
Selection 1 “Shunt Until Clear”. The Shock Sensor will be shunted from triggering upon remote
start, as long as vibration strong enough to activate the shock, and will remain shunted until the
vibration settles below the trigger threshold + 5 seconds, whereby it is reinstated.
Selection 2 “Shunt R/S Cycle”. Means that the shock sensor is shunted while under control of the
remote start. You have no shock detection while running under control of the remote start.
Selection 3 “Shunt From Transmitter”. Allows the customer to shut off shock from the transmitter
after the vehicle is remote started. Just activate the lock button of the transmitter after activating
the remote start will allow the shock sensor to be turned off for the one remote start cycle. It will be
reinstated upon next remote start unless the lock button is pressed.
