JBL, 5-CHANNEL MARINE AMPLIFIER 50 X 4 + 320 X 1 WATTS RMS

Specifications:

• 5-channel marine amplifier
• 50 Watts RMS x 4 + 320 Watts RMS x 1 at 4 Ohms
• 75 Watts RMS x 4 + 500 Watts RMS x 1 at 2 Ohms
• 100 Watts RMS x 2 Bridged at 4 Ohms + 500 Watts RMS x  at 2 Ohms
• Variable high and low pass filters(32-320 Hz, 12 dB / octave) on front and rear channels
• Low pass filter (32-320 Hz, 12 dB / octave) on subwoofer channel
• Bass boost on subwoofer channel (0-12 dB at 45 Hz)
• Phase switch on subwoofer channel (0, 180 degrees)
• Preamp and speaker-level inputs
• Fuse Rating: 30A x 3
• 4-gauge power and ground leads recommended – wiring and hardware not included with amplifier
• 360mm W x 51.3mm H x 180mm D

What’s In The Box: ​

• One marine A5055 five channel amplifier
• 4 Bare wire-to-RCA adapters
• Six 30A ATO fuses (3 installed, 3 spare)
• Remote bass control module
• 16.5′ Remote control cable (RJ-25 plugs on both ends)
• 2 Self-tapping screws for remote (M3 x 15mm)
• 4 Mounting screws (M4 x 53mm)
• Owner’s manual
• Two JBL stickers
• 1 Logo badge
