HIFONICS, 2000 WATTS GEMINI ELITE MONO SUBWOOFER CAR AUDIO AMPLIFIER.

Hifonics GEMINI Elite Mono subwoofer audio amplifier delivers 2000 watts with Hifonics High Fidelity that features Simpatico coil design (SPC) Ultra-Fi Pulse Width Modulated MOSFET power supply.

Specifications:

• CLASS: Super D Class™
• TOTAL CHANNELS: 1
• POWER @ 1 OHM (CH X WATTS): 1 x 2000
• POWER @ 2 OHMS (CH X WATTS): 1 x 1000
• POWER @ 4 OHMS (CH X WATTS): 1 x 500
• CROSSOVER: Variable Electronic 12dB Per Octave
• VARIABLE LOW PASS CROSSOVER 12DB PER
• OCTAVE: 40Hz-300Hz
• TONE CONTROL/PARAMETRIC EQ: Built-in bass control
• BASS BOOST: 0-9dB
• SUBSONIC FILTER: 10Hz-40Hz
• PHASE SHIFT: 0-180 Degrees
• VARIABLE VOLTAGE: .2 to 6V
• FREQUENCY RESPONSE: 10Hz-500Hz
• TOTAL HARMONIC DISTORTION (THD): < 0.10%
• SPEAKER LEVEL AUDIO INPUTS: Yes
• POWER TERMINAL 12V/GND: 4 AWG
• SPEAKER TERMINAL WIRE GAUGE: 12 AWG
• FUSING: 100A

​ Features

• LOW NOISE PREAMPLIFIER CIRCUIT: Maximum low voltage signal from the source unit comes into the amplifier circuit with minimal distortion.
• RCA INPUTS: Nickel plated high temperature impact resistant with hex screw terminals that allow for secure connections and is erosion resistant.
• HIGH LEVEL INPUTS: Easily tie into OEM audio systems that do not offer RCA output to maximize after market amplifier power.
• OPERATION MODE: Mono only.
• CROSSOVER TYPE: Variable Electronic: Electronic crossovers allow for complete control of the sound. See specifications for specific frequencies.
• ELECTRONIC EQUALIZER: Control of amplifier output with on-board electronic crossover to tailor specific frequencies to speakers and subwoofers.
• CLASS/TOPOLOGY: Super D-Class™: Hifonics has perfected the latest in digital chip technology to provide you with an extremely efficient, low temperature, high amplification system that others only dream about. There are several options for installation and the mono Super D-Class amplifiers can run at 1, 2 or 4-Ohm as well, for an even tighter bass response!
• OUTPUT DEVICE TECHNOLOGY: Ultra-Fi™ MOSFET: Produces high power with minimal distortion.
• HEAT SINK:
  High Grade Aluminum: Heavy duty aluminum alloy heat-sink allows amplifier to quickly dissipate heat while producing maximum power.
• POWER SUPPLY:
  Simpatico Coil Design: The dual coil Pulse Width Modulated power supply keeps voltage constant through the Ultra-Fi output devices.
• OUTPUT CONNECTIONS:
  RCA Outputs: Daisy chain multiple amplifier to eliminate additional signal cables from the source unit.
• CONNECTION TYPE:
  Secure molded connection terminal for all Power, Ground and Speaker connections. Angled for ease of access while creating a clean wire mangement profile.
• LED SYSTEM PROTECTION CIRCUITRY DIAGNOSTICS:
  Monitor overload and speaker short protection with illuminated indicators on the amplifier end panel.
• BASS REMOTE INCLUDED:
  Wired Bass Remote allows adjustments to bass frequencies from the control which can be mounted anywhere in the vehicle.​
