FORTIN FIT GUIDE

CLICK HERE TO LOOK UP FORTIN FIT GUIDE

Search for the BYPASS MODULES, T HARNESS REMOTE START ALARMS FOR VEHICLES

Simply pick the Make, Year, Model of the vehicle and all available products will be listed.
Also you may also search for your vehicle in the search box, example type in Camry or Maxima and a list will drop down for most recent model years.

______________________________________

To Integrate Fortin EVO-ALL  with Compustar RF Kits

First, make sure the EVO-ALL option H3 is selected.

Also make sure that you reverse the RX and TX wires in the Datalink.

Here is the programming for the remote to our EVO-ALL:

1.    Put the EVO-ALL in programming mode, release programming button on BLUE/RED

2.    Press and hold the programming button on EVO-ALL for 5 seconds. The 2 LED’s will shut down and turn back ON after 5 seconds.

3.    Turn the Ignition ON.

4.    Press the “Lock” or button on remote you wish to program.You can also press the “Start” button, but you will have to hold it for 3 seconds.

5.    The BLUE and RED LED’s will flash once to confirm remote is coded.

6.    To program additional remotes press the Lock or Start button of each remote.

  7.    Turn Ignition OFF once all remotes have been programmed.
