CRUNCH, V-DRIVE 2125 WATT TWO CHANNEL AMPLIFIER

Name: CRUNCH, V-DRIVE 2125 WATT TWO CHANNEL AMPLIFIER
SKU: DR-2125.2D
Availability: InStock

$66.00

Crunch V-Drive: low noise preamp, RCA inputs, Class D, adjustable crossover, LED protection, logo modes.

SKU: DR-2125.2D Categories: 2-Channel Amps, Amplifiers, Car Audio Tag: import

Specifications:

Amp Class: Class D
Amp Total Channels: 2
Amp Max Power (watts): 2125
Amp Power @ 2 Ohms (ch x watts): 2 x 1060
Amp Power @ 4 Ohms (ch x watts): 2 x 530
Amp Mono Bridged @ 4 Ohms (ch x watts): 1 x 2125
Amp Crossover: Variable Electronic 12dB Per Octave
Amp Variable High Pass Crossover 12dB per Octave: 40Hz-400Hz
Amp Variable Low Pass Crossover 12dB per Octave: 40Hz-400Hz
Amp Variable Voltage: 0.2-6V
Amp Signal to Noise: >100dB
Amp Frequency Response: 20Hz-20kHz
Amp Total Harmonic Distortion (THD): < 0.5%
Amp Speaker Level Audio Inputs: RCA
Amp Power Terminal 12v/GND: 4 AWG
Amp Speaker Terminal Wire Gauge: 8 GA
Amp Fusing: External 100A

The Crunch V-Drive amplifier features a low noise preamplifier circuit for minimal distortion, high-quality RCA inputs, and versatile operation modes including stereo, bridged mono, and simultaneous configurations. It offers fully adjustable 12dB crossovers and an electronic equalizer for precise frequency control. With an efficient Class D design, Crunch SPEED-FET MOSFETs enhance power and sound quality, while QTD Technology aluminum heat sinks ensure cool operation. The PWM power supply minimizes vehicle electrical strain, and nickel-plated brass terminals with screw-down connectors ensure secure, corrosion-resistant connections. LED diagnostics monitor protection, and selectable logo illumination modes provide customizable lighting effects.
