CRUNCH POWER ZONE CLASS D MONO AMP 3000 WATTS W/ BASS KNOB

$113.00

Crunch PZ-3020.1D POWERZONE 3000 Watt Mono Amplifier 1 Ohm Stable Ca

Out of stock

SKU: PZ30201D Category: Uncategorized Tag: import

Specifications
CLASS Class A/B
VARIABLE VOLTAGE 6V – 0.2V
SIGNAL TO NOISE >95dB
FREQUENCY RESPONSE 10Hz – 250Hz
CROSSOVER VeraCross
Variable VARIABLE LOW PASS CROSSOVER 12DB PER OCTAVE 40Hz – 300 Hz
BASS BOOST 0 – 12dB
SUBSONIC FILTER 10Hz – 40Hz
POWER @ 1 OHM 1 x 3000 Watts
POWER @ 2 OHMS 1 x 1500 Watts
POWER @ 4 OHMS 1 x 750 Watts
TOTAL CHANNELS 1
AUDIO INPUTS RCA
AUDIO OUTPUTS Full Range
RCA SPEAKER TERMINAL WIRE GAUGE
Spade Connector Recommended
FUSING 60Ax1
TOTAL HARMONIC DISTORTION (THD) <0.10%
Features & Benefits
LOW NOISE PRE-AMPLIFIER CIRCUITRY
Maximum low voltage signal from the source unit comes into the amplifier through a low voltage circuit which delivers minimal distortion through the amplification process
RCA INPUTS
Low voltage RCA inputs produce the highest sound quality connection with quality RCA materials helps prevent interference and minimize distortion in the signal path
OPERATION MODE
Mono only
CROSSOVER TYPE
Variable electronic crossovers allow for complete control of the sound
ELECTRONIC EQUALIZER
Control of amplifier output with on-board electronic crossover to tailor specific frequencies to speakers and subwoofers.
Check specifications for specific frequencies for this amplifier
CLASS / TOPOLOGY
Very efficient D-Class to drive additional power to subwoofer frequencies while remaining a small footprint
OUTPUT DEVICE TECHNOLOGY
Exclusive Crunch SPEED-FET MOSFET components maximize power efficiency while improving sound quality and minimizing distortion
HEAT SINK
QTD (Quick Thermal Dispersion) technology assures the amplifier makes huge power while running very cool with nearly undetectable musical distortions
POWER SUPPLY
Rugged MOSFET Pulse Width Modulation power supply
Allows amplifier to product efficient power without taxing the vehicle electrical system
OUTPUT CONNECTIONS
Nickel-plated brass connectionwith hex set screw terminals allow for secure connection and resist erosion
CONNECTION TYPE
Secure connection for all power, ground and speaker connections.
FULL-RANGE RCA OUTPUTS FOR SIGNAL PASS THROUGH
Daisy chain multiple amplifier to eliminate additional signal cables from the source unit
LED SYSTEM PROTECTION CIRCUITRY DIAGNOSTICS
Monitor overload and speaker short protection with illuminated indicators on the amplifier end panel
BASS REMOTE INCLUDED
Wired Bass Remote allows adjustments to bass frequencies from the control which can be mounted anywhere in the vehicle.

Brand

Crunch
