AUDIOPIPE, AUDIO MIXINH CONSOLE DSP AUDIO INTERFACE, 8 CHANNEL

Specifications:

• Input Channels
  • Mono: Mic / Line: 4
  • Stereo: Line or USB: 2
  • Stereo: Line or USB: 2​
• Output Channels
  • Stereo Out (Balance): 2
  • Stereo Out (Unbalance): 2
  • Monitor out: 2
  • Phones: 1
  • Stereo Return: 2
• Functions
  • HPF: 80Hz , 12dB/oct (Mono / Stereo: Mic only)
  • Phase: Normal / Reverse

  • COMP:

    • Threshold= + 22dB TO 8dB;
    • Attack: 0.5msec to 100sec;
    • Release: 2msec – 2sec;
    • Gain: -12dB to + 12dB;
    • Ratio: 1:1 TO 4:1

• 3 Band EQ: High / Mid / Low

​

• Frequency Response: 20Hz to 20KHz (-0.5dB)
• THD: < 0.01 % output = 0Db/1 KHz
• Signal to Noise Ratio: 70 dBu
• Built-in Effect: 16 programs, 24bit / 192KHz
• Phantom Power Voltage: +48V
• Power Requirements: AC 100-240V, 50/60Hz
•  Power Consumption: 7.5W Max

​

​
