AUDIOPIPE, 4 CHANNEL CLASS AB MOSFET AMPLIFIER

Specifications:

4 CHANNEL CLASS AB MOSFET AMPLIFIER

• RMS @ 4 Ohm (<1% Distortion): 4 x 100W
• RMS @ 2 Ohm (<1% Distortion): 4 x 150W
• Maximum Power Output: 2 x 280W
• THD: ≤0.5%
• Frequency Response (-3dB): 20Hz~20KHz
• Signal to noise ratio: >80dB
• Overheat Protect Temperature: 82°C/180°F
• Input Sensitivity: 0.2-6V
• Recommended fuse type: 35A x 2
• Current Draw: 70A
• Dimensions: 13.3″ x 7.3″ x 2.0″
• 338 x 185 x 52mm
